Li-Ion Type and 48V100Ah storage battery box

Cell

model

GLP150Ah

Capacity(0.5C)

150Ah

rated voltage(V)

3.2V

Typical Impedance (mΩ)

≤2mW

Battery material

Lifepo4 battery

Lithium ion phosphate battery

pack

Combination method

1P24S

Minimal capacity(0.5C)

150Ah

Nominal voltage

72V

Max. charge voltage

87.6V

Discharge cut-off voltage

          48V-60V

Max Charge current

75A

Max Working current

300A

Standard charge current

45A

Standard discharge current

75A

Pack Impedance standard

≤30mW

Weight (Approx.)

≈105.0Kg

Max. dimension(L×W×H)(mm)

≤ 970*470*155mm

Operating  temperature

Charge temperature

0℃~45℃

Discharge temperature

-20℃~55℃

 BMS

Single cell over-charge cut-off voltage

3.85V

over-charge release voltage

3.65V

Single cell under-discharge cut-off voltage

2.3V

Discharge release voltage

2.5V

Over-discharge cut-off current

300A

Over-discharge cut-off current delay

1.5S

Condition for the recovery of over-current and Short-circuit

Charging remove

Balance current

/

Balance Condition

/

Communication protocol

/
